Includes Fully Assembled Table and Servo Motor
The sophisticated-form machine with excellent operability and productivity
The single-thread, chainstitch, button sewing machine, which is frequently used for sewing buttons on men's wear and blouses under different sewing conditions, has been redesigned with its capabilities upgraded.
Assembled Table & Servo Motor
This Package includes a Fully Assembled Table and a Servo Motor.
Multiple Stitching Modes
Stitch shape can easily be changed over between 2 and 4 button-hole configurations only by operating a lever.
Speedy Sewing
The machine sews buttons with an optimum number of stitches; 8, 16 or 32, according to the sewing conditions.
Thread-Fray-Prevention On/Off Changeover Mechanism
The machine is provided as standard with a "thread-fray-prevention On/Off changeover mechanism to help produce beautiful seams with added durability.
Attachments
The attachments used for your conventional machines are applicable as they are.
Motor Options
Clutch motors operate at a fixed speed, typically between 1725 - 3450 rpm, depending on the type of machine. Servo Motors on the other hand are speed adjustable. The two major advantages of the Servo Motor are that you can control the speed of the motor and that the motor is completely silent when the pedal is not engaged.
Some other advantages of the Servo Motor include:
- They consume up to 90% less energy than clutch motors
- 1/3 lighter than clutch motors
- Reverse motor rotation with the flick of a switch
- Nothing to wear or adjust
- Adjusted speed remains the same no matter how hard the pedal is pressed
Most of our customers find that the sewing machine is much easier to control with a Servo motor because of the speed control. This is especially helpful for beginner sewers but also for projects that simply don't require high speed stitching.
| Machine Specifications | |
|---|---|
| Max. Sewing Speed | 1,500 Stitches per Minute |
| Number of Stitches | 8, 16 and 32 stitches |
| Needle | TQx1 (#16) #14~20 |
| Feed Length (crosswise feed) | 2.5~6.5mm |
| Feed Length (lengthwise feed) | 0~6.5mm |
| Applicable Button | Round-shaped Flat Button (2-holed, 4-holed), Shank button, Wrapped-around button, Snap, Label, Metal Button, Stay Button (exclusive attachments have to be used) |
| Button Size | ø10~28mm |
| Thickness of Button | 1.8~3.5mm (options max. 5mm) |
| Needle Bar Stroke | 48.6mm |
| Lift of the Presser Foot | 9mm |
| Lubrication | By an Oiler |
| Lubricating oil | JUKI New Defrix Oil No.1 (equivalent to ISO VG7) |
| Weight of the machine head | 24kg |
Create unlimited custom tabs and add any product detail, module, widget, design or HTML. Also possible to create custom tab layout using layout builder
Juki MB-1373 Single Thread Chain Button Sewing Industrial Machine Includes Table and Servo Motor
- Product Code: MB-1373
Includes Fully Assembled Table and Servo Motor
The sophisticated-form machine with excellent operability and productivity
The single-thread, chainstitch, button sewing machine, which is frequently used for sewing buttons on men's wear and blouses under different sewing conditions, has been redesigned with its capabilities upgraded.
Assembled Table & Servo Motor
This Package includes a Fully Assembled Table and a Servo Motor.
Multiple Stitching Modes
Stitch shape can easily be changed over between 2 and 4 button-hole configurations only by operating a lever.
Speedy Sewing
The machine sews buttons with an optimum number of stitches; 8, 16 or 32, according to the sewing conditions.
Thread-Fray-Prevention On/Off Changeover Mechanism
The machine is provided as standard with a "thread-fray-prevention On/Off changeover mechanism to help produce beautiful seams with added durability.
Attachments
The attachments used for your conventional machines are applicable as they are.
Motor Options
Clutch motors operate at a fixed speed, typically between 1725 - 3450 rpm, depending on the type of machine. Servo Motors on the other hand are speed adjustable. The two major advantages of the Servo Motor are that you can control the speed of the motor and that the motor is completely silent when the pedal is not engaged.
Some other advantages of the Servo Motor include:
- They consume up to 90% less energy than clutch motors
- 1/3 lighter than clutch motors
- Reverse motor rotation with the flick of a switch
- Nothing to wear or adjust
- Adjusted speed remains the same no matter how hard the pedal is pressed
Most of our customers find that the sewing machine is much easier to control with a Servo motor because of the speed control. This is especially helpful for beginner sewers but also for projects that simply don't require high speed stitching.
| Machine Specifications | |
|---|---|
| Max. Sewing Speed | 1,500 Stitches per Minute |
| Number of Stitches | 8, 16 and 32 stitches |
| Needle | TQx1 (#16) #14~20 |
| Feed Length (crosswise feed) | 2.5~6.5mm |
| Feed Length (lengthwise feed) | 0~6.5mm |
| Applicable Button | Round-shaped Flat Button (2-holed, 4-holed), Shank button, Wrapped-around button, Snap, Label, Metal Button, Stay Button (exclusive attachments have to be used) |
| Button Size | ø10~28mm |
| Thickness of Button | 1.8~3.5mm (options max. 5mm) |
| Needle Bar Stroke | 48.6mm |
| Lift of the Presser Foot | 9mm |
| Lubrication | By an Oiler |
| Lubricating oil | JUKI New Defrix Oil No.1 (equivalent to ISO VG7) |
| Weight of the machine head | 24kg |
- Brand: Juki
- Viewed: 28
- Availability: In Stock
$3,799.00
