Features

large bobbin and horizontal axis transverse rotary hook

Wide Zig-Zag - Locking Zig-Zag width regulator

Straight stitcher when zig-zag is set to 0mm

Upper feed mechanism helps avoid slippage when sewing

Reverse stitching

Maximum width of zig-zag : 3/8" (9.5 mm)

Long arm with 10" free space between needle and arm

Specifications

Max Speed (S.P.M.) (Speed depends on thread, material and operation.)

- Zig-Zag Stitch - 3000 for stitches -1A and -3A; 2700 for stitch -2A

- Straight Stitch - 3200 for stitches -1A and -3A; 3000 for stitch -2A

Clearance Under Foot - 25/64" (10 mm)

Needle Bar Stroke - 1 11/32" (34 mm)

Max Stitch Length - 5 s.p.i. (5 mm)

Needle - 135 X 17

Bobbin Metal - 2120304-312

Bobbin Pre-wound - M

Hook - B79

Work Space - 10" (255 mm)

Bed Size - 7" x 18 7/8" (178 x 480 mm)

Zig-Zag Max Width - 3/8" (9.5 mm)

Applications:

Stitch -1A:

- used for a wide range of products and operations such as edge sewing, patch sewing, attaching and abutting work, applique work and binding on such materials as leather, vinyl, canvas, cloth, lace and similar materials

Stitch -2A: (CURRENTLY VIEWING)

- For sewing elastic and other stretch materials, as well as for ornamental stitching

- For stitching such products as boat and truck covers, tents, awnings, sails, parachutes, tarpaulins, canvas bags also many items of military and naval equipment

- Used on such materials as canvas, nylon, vinyl, leather, synthetics and similar materials

- Especially desirable where reinforced stitch is necessary

- Also available with special fittings for rope tacking operations

- Used for rope tacking, making loops in rope and attaching small and medium size ropes to such products as truck covers, tents, sails, hammocks, parachutes, grain bags and many items of military and naval equipment

Stitch -3A:

- Performs similar operations as Model 199R-2A-1 with the added advantage of making an additional stitch for extra reinforcement

Motor Options

With so many options available for motors when we talk about replacing or buying a motor for our industrial sewing machine, there is one important point to keep always in mind "The Speed". Regardless of brand or price, motors come in two different configurations:

1. Variable Speed Servo Motor

2. Adjustable-Speed Servo Motor

Clutch motors operate at a fixed speed, typically between 1725 - 3450 rpm, depending on the type of machine. Servo Motors on the other hand are speed adjustable. The two major advantages of the Servo Motor are that you can control the speed of the motor and that the motor is completely silent when the pedal is not engaged.

Some other advantages of the Servo Motor include:

They consume up to 90% less energy than clutch motors

1/3 lighter than clutch motors

Reverse motor rotation with the flick of a switch

Nothing to wear or adjust

Adjusted speed remains the same no matter how hard the pedal is pressed

Most of our customers find that the sewing machine is much easier to control with a Servo motor because of the speed control. This is especially helpful for beginner sewers but also for projects that simply don't require high speed stitching.

This machine package includes a servo motor.
